Nuctech™ CX180180D
X-Ray Pallet Scanner
X-ray Inspection System for Merchandise
The NUCTECH ™ CX180180D Inspection System is a new generation double energy double sight X-ray inspection machine for large packages and pallet loading.
With its double-view design, images are displayed on a special monitor. It has the ability to identify and locate hidden dangerous and contraband objects underneath overlapping areas.
It stands out for its modern and ergonomic design for an efficient and professional X-ray examination. With wide tunnel dimensions of 1850mm width and 1806mm height, it is perfectly suitable for inspecting large luggage, pallet loads at airports, customs, railway stations, ports, logistics and warehouse companies and more.
INSPECT
Explosives
Liquids
Narcotics
Baggage
Weapons
Batteries
TECHNICAL DATA
Tunnel dimensions
1850mm(W)×1806mm(H)
Maximum load
2000kg
Power supply
220VAC / 110VAC (-15%~+10%), 50Hz / 60Hz±3Hz
Energy consumption
2.5kVA
WARRANTY & SUPPORT
12 months, includes corrective maintenance service with spare parts included.
